Universal water swivel

  • Product No.:GV-WS-01
  • Price:$300
  • MOQ:1 pc
  • Delivery time:1 to 10 days
  • Sizes:BQ, NQ, HQ, PQ, AW, BW, NW, HW, PW, HWT, PWT
  • Country of origin:China
  • Online Inquiry

Guizhou Vilong Universal water swivel is designed to facilitate water or other drilling fluid to the inside of the drill bits for cooling and removing the cuttings while drilling, which is connected between pump and the top of the drill rod string by a high pressure hose.

Subs are available to adapt to all BQ, NQ, HQ, PQ, AW, BW, NW, HW, PW, HWT, PWT drill rods and casing tubes.






ID #

Description

QTY

Unit weight (kg)

1-15

GV-01 Universal Water Swivel

1

14.40

1

Water Swivel Hoist Cap

1

6.30

1A

Hose Joint

1

0.50

2

Compression Spring

1

0.02

3

Packing

1

0.05

4

O-ring

1

0.01

5

Packing Housing

1

1.00

6

Loading Nut

1

0.20

7

Belleville Washer

1

0.01

8

Thrust Washer

1

0.01

9

Extension Spindle

1

0.30

10

Internal Circlip

1

0.02

11

Ball Bearing

1

0.70

12

Swivel Spindle

1

1.70

13

Ball Bearing

1

0.70

14

Water Swivel Body

1

3.10

15

Hydraulic Grease Fitting

1

0.01
